Interviewer: Can you tell me what are the commonly used network models?

Network I/O models are the policies and mechanisms that determine how a system manages and processes input and output operations. They are critical for efficient data transfer, handling multiple concurrent connections, and optimizing performance.

The following are the main network I/O models and their use cases:


01 Blocking I/O Model

In the blocking I/O model, the execution of a thread is suspended until the I/O operation is completed. During this time, the thread cannot perform any other tasks.

Usage scenarios

• Simple applications with minimal I/O requirements.
• Simplicity and ease of use of the system are more important than performance.
• The number of concurrent connections is small.

02 Non-blocking I/O model

In a nonblocking I/O model, an I/O operation returns immediately, even if the data is not yet available. The application can perform other tasks while waiting for the I/O operation to complete.

Usage scenarios

• Applications that require a responsive user interface.
• Systems that need to handle multiple I/O operations simultaneously.
• Blocking would cause unacceptable delays in real-time systems.

03 I/O multiplexing model

I/O multiplexing uses mechanisms such as select(), poll(), or epoll() to monitor multiple I/O streams simultaneously. The application is notified when one or more I/O operations can be performed without blocking.

Usage scenarios

• A server that handles multiple client connections.
• Network applications that need to efficiently manage multiple connections.
• Event-driven architecture.

04 Asynchronous I/O Model

In the asynchronous I/O model, the application initiates an I/O operation and continues processing. When the I/O operation is complete, the system notifies the application, typically through a callback or signal.

Usage scenarios

• High performance and high throughput applications.
• Systems that require minimal latency and high concurrency.
• Applications that benefit from parallel and asynchronous execution.

05 Signal driven I/O

Signal-driven I/O (SIGIO) is a mechanism in Unix-like operating systems that allows a process to be asynchronously notified when an I/O operation can be performed on a file descriptor without blocking. Specifically, a signal (usually SIGIO) is sent to the process when the file descriptor can be read or written.

Usage scenarios

• High-performance network servers: Signal-driven I/O can be used to efficiently handle multiple client connections. When a connection is ready to read or write data, the server is notified via SIGIO and can then process the data without blocking other connections.
• Event-driven architecture: Systems designed around an event-driven architecture can benefit from signal-driven I/O, using signals to trigger event handlers when I/O operations can occur.
• Embedded Systems: In resource-constrained environments such as embedded systems, signal-driven I/O helps achieve non-blocking I/O operations with minimal overhead.

06 Choose the right model

The choice of network I/O model depends on application requirements, performance considerations, complexity, and the environment in which the application runs. For example:

• Blocking I/O may be suitable for simple, low-concurrency applications.
• Non-blocking I/O and I/O multiplexing are often used in network servers that need to efficiently handle multiple concurrent connections.
• In high-performance, high-concurrency applications, asynchronous I/O is preferred, and non-blocking operations and callbacks or completion handlers can improve throughput and responsiveness.
• The event-driven model is well suited for applications that require a responsive user interface or that leverage an event loop for efficient task management.
