Communication Protocol I2C Subsystem I2C Driver

Now let's write the I2C Driver part.

The I2C driver is written in four parts:

 I2C SW Architecture
 I2C Data Structure
 I2C Register Flow
 I2C Data Transfer

This article takes the MTK platform as an example. The code comes from Xiaomi's open source project. Every time Xiaomi makes a mobile phone project, it will open source the kernel part because it must follow the GPL agreement.

 https://github.com/MiCode/Xiaomi_Kernel_OpenSource ​ ​ ​ ​

I2C driver source code directory.

 / kernel- 5.10 / drivers / i2c / i2c-core-base.c // Linux common driver
 /kernel-5.10/drivers/i2c/i2c-core.h ​ ​ ​ ​ ​
 /kernel-5.10/include/linux/i2c.h ​ ​ ​ ​ ​
 / kernel- 5.10 / drivers / i2c / busses / i2c-mt65xx.c // i2c controller driver
 /kernel-5.10/arch/arm64/boot/dts/ ​ ​ ​ ​ ​
 demo
 /kernel-5.10/drivers/input/touchscreen/ ​ ​ ​ ​

1. I2C SW Architecture

The driver layer is the responsibility of ordinary driver engineers, the i2c core layer is provided by Linux, and the chip manufacturer is responsible for the layers below the i2c core layer.

The I2C subsystem separates the I2C device driver and the I2C bus driver through i2c-core, so that the I2C device driver does not need to worry about the details of the I2C bus transmission and can focus on the implementation of the I2C device logic.

The abstraction is as follows:

The focus of I2C bus driver is I2C adapter (controller) driver, which uses two important data structures: i2c_adapter and i2c_algorithm. Among them, Linux kernel abstracts SOC's I2C adapter (controller) into i2c_adapter, and i2c_algorithm is just a collection of implementation functions of some i2c transmission.

In Linux system, there are the following nodes:

2. I2C Data Structure

If we want to understand a Linux subsystem, we must study its data structure and understand what each structure stores, so that we can sort out the architecture of the subsystem.

The I2C subsystem has several main structures:

 I2C controller: i2c_adapter , i2c_algorithm , mtk_i2c
 I2C device drivers: i2c_client , i2c_driver
 I2C transmission: i2c_msg

i2c_adapter: The i2c-core layer describes an I2C controller. If a chip has 8 I2C buses, there are 8 i2c_adapters. Please read the blogger's comments on the code in detail .

 struct i2c_adapter {
 struct module * owner ;
 unsigned int class ; /* What types of slave devices does the I2C bus support? */
 const struct i2c_algorithm * algo ; /* the algorithm to access the bus */
 void * algo_data ;
 /* data fields that are valid for all devices */
 const struct i2c_lock_operations * lock_ops ;
 struct rt_mutex bus_lock ;
 struct rt_mutex mux_lock ;
 int timeout ; /* Cannot resend after this time*/
 int retries ; /* I2C send failure retry times */
 struct device dev ; /* the adapter device */
 unsigned long locked_flags ; /* owned by the I2C core */
 #define I2C_ALF_IS_SUSPENDED 0
 #define I2C_ALF_SUSPEND_REPORTED 1
 int nr ; /*I2C bus id*/
 char name [ 48 ];
 struct completion dev_released ;
 struct mutex userspace_clients_lock ;
 struct list_head userspace_clients ;
 struct i2c_bus_recovery_info * bus_recovery_info ;
 const struct i2c_adapter_quirks * quirks ;
 struct irq_domain * host_notify_domain ;
 struct regulator * bus_regulator ;
 };

i2c_algorithm: A collection of I2C transmission functions, of which master_xfer is the real transmission function, which must be implemented by the chip manufacturer when writing an I2C controller driver. The functionality function returns what communication protocol the I2C controller supports, which also needs to be implemented. Even if Linux specifies other functions, the chip manufacturer may not implement them because they are not commonly used.

 struct i2c_algorithm {
 int (* master_xfer )( struct i2c_adapter * adap , struct i2c_msg * msgs , int num );
 int (* master_xfer_atomic )( struct i2c_adapter * adap , struct i2c_msg * msgs , int num );
 int (* smbus_xfer )( struct i2c_adapter * adap , u16 addr , unsigned short flags , char read_write , u8 command , int size , union i2c_smbus_data * data );
 int (* smbus_xfer_atomic )( struct i2c_adapter * adap , u16 addr , unsigned short flags , char read_write , u8 command , int size , union i2c_smbus_data * data );
 /* To determine what the adapter supports */
 u32 (* functionality )( struct i2c_adapter * adap );
 #if IS_ENABLED ( CONFIG_I2C_SLAVE )
 int (* reg_slave )( struct i2c_client * client );
 int (* unreg_slave )( struct i2c_client * client );
 #endif
 };

MTK only implements two of them.

i2c_client: describe device information:

 struct i2c_client {
 unsigned short flags ; /* I2C transmission flags are as follows*/
 #define I2C_CLIENT_PEC 0x04 /* Use Packet Error Checking */
 #define I2C_CLIENT_TEN 0x10 /* we have a ten bit chip address */
 /* Must equal I2C_M_TEN below */
 #define I2C_CLIENT_SLAVE 0x20 /* we are the slave */
 #define I2C_CLIENT_HOST_NOTIFY 0x40 /* We want to use I2C host notify */
 #define I2C_CLIENT_WAKE 0x80 /* for board_info; true iff can wake */
 #define I2C_CLIENT_SCCB 0x9000 /* Use Omnivision SCCB protocol */
 /* Must match I2C_M_STOP|IGNORE_NAK */
 unsigned short addr ; /* chip address - NOTE: 7bit */
 /* addresses are stored in the */
 /* _LOWER_ 7 bits */
 char name [ I2C_NAME_SIZE ];
 struct i2c_adapter * adapter ; /* Which I2C bus it is on */
 struct device dev ; /* the device structure */
 int init_irq ; /* irq set at initialization */
 int irq ; /* irq issued by device */
 struct list_head detected ;
 #if IS_ENABLED ( CONFIG_I2C_SLAVE )
 i2c_slave_cb_t slave_cb ; /* callback for slave mode */
 #endif
 void * devres_group_id ; /* ID of probe devres group */
 };

i2c_driver: When ordinary driver engineers write drivers, they must implement the probe function and remove function. The remaining functions are generally not used.

 struct i2c_driver {
 unsigned int class ;
 /* Standard driver model interfaces */
 int (* probe )( struct i2c_client * client , const struct i2c_device_id * id );
 int (* remove )( struct i2c_client * client );
 int (* probe_new )( struct i2c_client * client );
 void (* shutdown )( struct i2c_client * client );
 void (* alert )( struct i2c_client * client , enum i2c_alert_protocol protocol , unsigned int data );
 int (* command )( struct i2c_client * client , unsigned int cmd , void * arg );
 struct device_driver driver ;
 const struct i2c_device_id * id_table ;
 int (* detect )( struct i2c_client * client , struct i2c_board_info * info );
 const unsigned short * address_list ;
 struct list_head clients ;
 };

mtk_i2c: The MTK platform uses this structure to represent the I2C controller, which is defined in /kernel-5.10/drivers/i2c/busses/i2c-mt65xx.c.

 struct mtk_i2c {
 struct i2c_adapter adap ; /* i2c host adapter */
 struct device * dev ;
 struct completion msg_complete ;
 /* set in i2c probe */
 void __iomem * base ; /* i2c base addr */
 void __iomem * pdmabase ; /* dma base address*/
 struct clk * clk_main ; /* main clock for i2c bus */
 struct clk * clk_dma ; /* DMA clock for i2c via DMA */
 struct clk * clk_pmic ; /* PMIC clock for i2c from PMIC */
 bool have_pmic ; /* can use i2c pins from PMIC */
 bool use_push_pull ; /* IO config push-pull mode */
 u16 irq_stat ; /* interrupt status */
 unsigned int clk_src_div ;
 unsigned int speed_hz ; /* The speed in transfer */
 enum mtk_trans_op op ;
 u16 timing_reg ;
 u16 high_speed_reg ;
 unsigned char auto_restart ;
 bool ignore_restart_irq ;
 const struct mtk_i2c_compatible * dev_comp ;
 };

i2c_msg: i2c_msg must be filled when I2C reads or writes.

Flag bit: written as 0, read as I2C_M_RD, you can refer to other flags.

The maximum value of a single I2C transfer is 64KB, and the blogger has explained the length of len in the comments.

 struct i2c_msg {
 __u16 addr ;
 __u16 flags ;
 #define I2C_M_RD 0x0001 /* guaranteed to be 0x0001! */
 #define I2C_M_TEN 0x0010 /* use only if I2C_FUNC_10BIT_ADDR */
 #define I2C_M_DMA_SAFE 0x0200 /* use only in kernel space */
 #define I2C_M_RECV_LEN 0x0400 /* use only if I2C_FUNC_SMBUS_READ_BLOCK_DATA */
 #define I2C_M_NO_RD_ACK 0x0800 /* use only if I2C_FUNC_PROTOCOL_MANGLING */
 #define I2C_M_IGNORE_NAK 0x1000 /* use only if I2C_FUNC_PROTOCOL_MANGLING */
 #define I2C_M_REV_DIR_ADDR 0x2000 /* use only if I2C_FUNC_PROTOCOL_MANGLING */
 #define I2C_M_NOSTART 0x4000 /* use only if I2C_FUNC_NOSTART */
 #define I2C_M_STOP 0x8000 /* use only if I2C_FUNC_PROTOCOL_MANGLING */
 __u16 len ; //Unsigned 16 bits, 65536 bytes , a maximum of 64KB for one I2C transfer
 __u8 * buf ;
 };
 I2C_M_NO_RD_ACK : Ignore all ACK / NACK and keep reading
 I2C_M_IGNORE_NAK : Ignore all NACKs and continue reading
 I2C_M_NOSTART : No START signal
