gRPC services communicating through the Istio mesh

[[433796]]

introduction

This article verifies the communication process of gRCP service consumer mesha and gRPC service provider meshb deployed in the Istio mesh. This example makes it easier to connect an external registry to the mesh.

1. Isito configuration tips

Isito has been installed in the Kubernetes cluster, and the following parameters are checked to see if they are set correctly.

istio-config.yaml content

 ---
 apiVersion: install.istio.io/v1alpha1
 kind: IstioOperator
 spec:
 profile: default
 values ​​:
 global :
 logging:
 level : default :debug
 meshConfig:
    accessLogFile: /dev/stdout
 defaultConfig:
      holdApplicationUntilProxyStarts: true
 proxyMetadata:
        ISTIO_META_DNS_CAPTURE: "true"
        ISTIO_META_DNS_AUTO_ALLOCATE: "true"
 components:
 Pilot:
 hub: istio
 tag: 1.10.4

Key Parameters

Execute the following command to take effect

 istioctl install -y -f istio-config.yaml

Verify the configuration after it takes effect by running the following command

 kubectl describe IstioOperator installed-state -n istio-system >> istioOperator.conf

2. Example

Defining Proto

The client and server communicate through the simple method SayHello.

 syntax = "proto3" ;

 option java_multiple_files = true ;
 option java_package = "com.melon.test.client.grpc" ;
 option java_outer_classname = "HelloMesh" ;

 package meshgrpc;

 service Mesher {

  rpc SayHello (HelloRequest) returns (HelloReply) {}
 }

 message HelloRequest {
 string name = 1;
 }

 message HelloReply {
 string message = 1;
 }

Service consumer mesha

 @RestController
 public class MeshSender {

 @GetMapping( "demo" )
 public String meshWorker(){

         String target = "dns:///AppMeshClient.mesh:50000" ;
        // String target = "127.0.0.1:50000" ;
        ManagedChannel channel = ManagedChannelBuilder.forTarget(target)
                .usePlaintext()
 .build();
        MesherGrpc.MesherBlockingStub blockingStub = MesherGrpc.newBlockingStub(channel);
        HelloRequest request = HelloRequest.newBuilder().setName( "mesh demo!" ).build();
        HelloReply reply = blockingStub.sayHello(request);
        System. out .println(reply.getMessage());
 return reply.getMessage();

 }
 }

Service provider meshb

 @Component
 public class MeshReceiver {


 @PostConstruct
 public void receiverWorker() throws IOException {
 int port = 50000;
    Server server = ServerBuilder.forPort(port)
      .addService(new MeshBService())
 .build()
 .start();
    System. out .println( "Server started." );
 }

  class MeshBService extends MesherGrpc.MesherImplBase {

 public void sayHello(HelloRequest request,
                         io.grpc.stub.StreamObserver<HelloReply> responseObserver) {

      System. out .println( "receiver client message: " + request.getName());
      HelloReply reply = HelloReply.newBuilder().setMessage( "I'm from server " + request.getName()).build();
      responseObserver.onNext(reply);
      responseObserver.onCompleted();
 }
 }

 }

Image push

 <plugin>
  <groupId>com.google.cloud.tools</groupId>
  <artifactId>jib-maven-plugin</artifactId>
 <version>3.1.4</version>
 <configuration>
 < from >
 <image>
        harbor.xx/x/java:8u212- full
 </image>
 <auth>
        <username>${harbor.username}</username>
        < password >${harbor. password }</ password >
 </auth>
 </ from >
 < to >
      <image>xxx/x/${project. name }</image>
 <auth>
        <username>${harbor.username}</username>
        < password >${harbor. password }</ password >
 </auth>
 <tags>
        <tag>${project.version}</tag>
 <tag>latest</tag>
 </tags>
 </ to >
 <container>
 <ports>
 <port>x</port>
 </ports>
      <creationTime>USE_CURRENT_TIMESTAMP</creationTime>
 </container>
 </configuration>
 </plugin>

Note: Use the Maven plugin jib to execute the following command "mvn compile jib:build" to push the image to the harbor repository

3. gRPC Service Provider Deployment

Set up the Deployment of the meshb service

 ---
 apiVersion: apps/v1
 kind: Deployment
 metadata:
 name : meshb
 labels:
 app: meshb
 spec:
 selector:
 matchLabels:
 app: meshb
 replicas: 1
 template:
 metadata:
 labels:
 app: meshb
 spec:
 imagePullSecrets:
 - name : xxxx #warehouse name
 containers:
 - name : meshb
          image: xxxx/x/meshb:latest
          imagePullPolicy: Always
 ports:
            - containerPort: 50000

Execute the following command to take effect

 kubectl apply -f meshb.yaml
 deployment.apps/meshb created

Check the running status is normal

 # kubectl get pods
 NAME READY STATUS RESTARTS AGE
 meshb-565945d794-wcb8z 2/2 Running 0 9m19s

Check the startup log to see if the startup is successful

 # kubectl logs meshb-565945d794-wcb8z -n default

 Server started.
 2021-11-05 09:21:19.828 INFO 1 --- [main] osbwembedded.tomcat.TomcatWebServer: Tomcat started on port(s): 8181 (http) with context path ''
 2021-11-05 09:21:19.847 INFO 1 --- [main] com.melon.test.MeshbApplication : Started MeshbApplication in 3.859 seconds (JVM running for 4.344)

Note: At this point, the gRPC service provider has been deployed.

4. gRPC Service Consumer Deployment

Set up the Deployment of the mesha service

 ---
 apiVersion: apps/v1
 kind: Deployment
 metadata:
 name : mesha
 labels:
 app: mesha
 spec:
 selector:
 matchLabels:
 app: mesha
 replicas: 1
 template:
 metadata:
 labels:
 app: mesha
 spec:
 imagePullSecrets:
 - name : middleware
 containers:
 - name : mesha
          image: harbor.hellobike.cn/base/mesha:latest
 ports:
            - containerPort: 7171
          imagePullPolicy: Always
 ---
 apiVersion: v1
 kind: Service
 metadata:
 name : mesha
 spec:
 selector:
 app: mesha
 type: LoadBalancer
 ports:
 - name : web

Execute command deployment

 # kubectl apply -f mesha.yaml

 deployment.apps/mesha created

 service/mesha created

View service status

 # kubectl get service
 NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
 mesha LoadBalancer 10.x.61.x <pending> 7171:30514/TCP 20s

View Pod Running Status

 # kubectl get pods
 NAME READY STATUS RESTARTS AGE
 mesha-b559fc4f4-m9752 2/2 Running 0 87s

Note: At this point, the service consumer has been deployed.

4. Service call verification

Access by domain name

 http://xxxx:30514/demo

The page prints the following error

Check the log and find that the domain name cannot be resolved:

 kubectl logs -f mesha-b559fc4f4-m9752 -n default

 2021-11-05 09:01:37.372 WARN 1 --- [ault-executor-0] io.grpc.internal.ManagedChannelImpl : [Channel<1>: (dns:///AppMeshClient.mesh:50000)] Failed to resolve name. status=Status{code=UNAVAILABLE, description=Unable to resolve host AppMeshClient.mesh, cause=java.lang.RuntimeException: java.net.UnknownHostException: AppMeshClient.mesh: Name or service not known
 at io.grpc.internal.DnsNameResolver.resolveAll(DnsNameResolver.java:436)
 at io.grpc.internal.DnsNameResolver$Resolve.resolveInternal(DnsNameResolver.java:272)
 at io.grpc.internal.DnsNameResolver$Resolve.run(DnsNameResolver.java:228)
 at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1149)
 at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:624)
 at java.lang.Thread.run(Thread.java:748)
 Caused by : java.net.UnknownHostException: AppMeshClient.mesh: Name   or service not known
 at java.net.Inet4AddressImpl.lookupAllHostAddr(Native Method)
 at java.net.InetAddress$2.lookupAllHostAddr(InetAddress.java:929)
 at java.net.InetAddress.getAddressesFromNameService(InetAddress.java:1324)
 at java.net.InetAddress.getAllByName0(InetAddress.java:1277)
 at java.net.InetAddress.getAllByName(InetAddress.java:1193)
 at java.net.InetAddress.getAllByName(InetAddress.java:1127)
 at io.grpc.internal.DnsNameResolver$JdkAddressResolver.resolveAddress(DnsNameResolver.java:646)
 at io.grpc.internal.DnsNameResolver.resolveAll(DnsNameResolver.java:404)
 ... 5 more
 }

Mapping the service provider IP through ServiceEntry

Check the IP address of the service provider meshb is xx0.17

 # kubectl get pods -o wide
 NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
 mesha-b559fc4f4-m9752 2/2 Running 0 140m xx1.117 k8s-servicemesh-3 <none> <none>
 meshb-565945d794-wcb8z 2/2 Running 0 118m xx0.17 k8s-servicemesh-1 <none> <none>

meshb-service-entry.yaml content

 apiVersion: networking.istio.io/v1alpha3
 kind: ServiceEntry
 metadata:
 name : meshb
 spec:
 endpoints:
 - address: xx0.17
 hosts:
 - AppMeshClient.mesh
 location: MESH_INTERNAL
 ports:
 - name : grpc
 number: 50000
 protocol: grpc
 resolution: STATIC

Execute the following command to make ServiceEntry effective

 kubectl apply -f meshb-service-entry.yaml
 serviceentry.networking.istio.io/meshb created

Visit the page again and find that it is normal

Note: At this point, the service consumer initiates a call to the service provider in the grid.

5. Log verification tracking

View the service consumer mesha log

 kubectl logs -f mesha-b559fc4f4-m9752 -n default

 I'm from server mesh demo!

Note: Information returned by the service consumer mesha from the service provider meshb.

View the service provider meshb log

 # kubectl logs -f meshb-565945d794-wcb8z -n default

 2021-11-05 09:21:19.828 INFO 1 --- [main] osbwembedded.tomcat.TomcatWebServer: Tomcat started on port(s): 8181 (http) with context path ''
 2021-11-05 09:21:19.847 INFO 1 --- [main] com.melon.test.MeshbApplication : Started MeshbApplication in 3.859 seconds (JVM running for 4.344)
 receiver client message: mesh demo!

Note: The service provider meshb received the request from the service consumer mesha.

View the envoy log of the service consumer mesha

 kubectl logs -f -l app=mesha -c istio-proxy -n default
 2021-11-05T10:25:17.772317Z info xdsproxy connected to upstream XDS server: istiod.istio-system.svc:15012
 2021-11-05T10:52:35.856445Z warning envoy config StreamAggregatedResources gRPC config stream closed: 14, transport is closing
 2021-11-05T10:52:36.093048Z info xdsproxy connected to upstream XDS server: istiod.istio-system.svc:15012
 [2021-11-05T11:06:23.510Z] "GET /demo HTTP/1.1" 500 - via_upstream - "-" 0 287 37 36 "-"   "Mozilla/5.0 (Macintosh; Intel Mac OS X 10_15_7) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/95.0.4638.54 Safari/537.36"   "49cd74d8-86eb-4ef5-bd71-8236d188c2f9"   "10.69.31.156:30514"   "10.166.1.117:7171" inbound|7171|| 127.0.0.6:41007 10.166.1.117:7171 10.166.0.0:20826 - default
 2021-11-05T11:22:58.633956Z warning envoy config StreamAggregatedResources gRPC config stream closed: 14, transport is closing
 2021-11-05T11:22:59.100387Z info xdsproxy connected to upstream XDS server: istiod.istio-system.svc:15012
 [2021-11-05T11:27:23.842Z] "POST /meshgrpc.Mesher/SayHello HTTP/2" 200 - via_upstream - "-" 17 33 371 319 "-"   "grpc-java-netty/1.28.0"   "79f2edbd-9c31-4265-87fb-38a594d9383b"   "AppMeshClient.mesh:50000"   "10.166.0.17:50000" outbound|50000||AppMeshClient.mesh 10.166.1.117:51914 240.240.0.63:50000 10.166.1.117:40544 - default
 [2021-11-05T11:27:23.527Z] "GET /demo HTTP/1.1" 200 - via_upstream - "-" 0 26 729 728 "-"   "Mozilla/5.0 (Macintosh; Intel Mac OS X 10_15_7) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/95.0.4638.54 Safari/537.36"   "859344b6-012d-4457-a391-2b4d13aa3e35"   "10.69.31.156:30514"   "10.166.1.117:7171" inbound|7171|| 127.0.0.6:47065 10.166.1.117:7171 10.166.0.0:2410 - default

View the envoy log of the service consumer meshb

 # kubectl logs -f -l app=meshb -c istio-proxy -n default
 2021-11-05T09:57:12.490428Z warning envoy config StreamAggregatedResources gRPC config stream closed: 14, transport is closing
 2021-11-05T09:57:12.765887Z info xdsproxy connected to upstream XDS server: istiod.istio-system.svc:15012
 2021-11-05T10:24:48.767511Z warning envoy config StreamAggregatedResources gRPC config stream closed: 14, transport is closing
 2021-11-05T10:24:48.914475Z info xdsproxy connected to upstream XDS server: istiod.istio-system.svc:15012
 2021-11-05T10:57:52.604281Z warning envoy config StreamAggregatedResources gRPC config stream closed: 14, transport is closing
 2021-11-05T10:57:52.757736Z info xdsproxy connected to upstream XDS server: istiod.istio-system.svc:15012
 2021-11-05T11:26:56.551824Z warning envoy config StreamAggregatedResources gRPC config stream closed: 14, transport is closing
 2021-11-05T11:26:56.987345Z info xdsproxy connected to upstream XDS server: istiod.istio-system.svc:15012
 [2021-11-05T11:27:23.844Z] "POST /meshgrpc.Mesher/SayHello HTTP/2" 200 - via_upstream - "-" 17 33 333 316 "-"   "grpc-java-netty/1.28.0"   "79f2edbd-9c31-4265-87fb-38a594d9383b"   "AppMeshClient.mesh:50000"   "10.166.0.17:50000" inbound|50000|| 127.0.0.6:44221 10.166.0.17:50000 10.166.1.117:51914 - default

Log in to mesha's Pod to verify

 kubectl describe pod/mesha-b559fc4f4-m9752 -n default
 [12:04:44root@mesha-b559fc4f4-m9752 /] C:2
 # curl -v AppMeshClient.mesh
 * About   connect () to AppMeshClient.mesh port 80 (#0)
 * Trying 240.240.0.63...
 * Connected to AppMeshClient.mesh (240.240.0.63) port 80 (#0)
 > GET / HTTP/1.1
 > User -Agent: curl/7.29.0
 > Host: AppMeshClient.mesh
 > Accept: */*
 >
 < HTTP/1.1 503 Service Unavailable
 < content-length: 91
 < content-type: text/plain
 < date : Fri, 05 Nov 2021 12:04:59 GMT
 < server:envoy
 <
 * Connection #0 to host AppMeshClient.mesh left intact
 upstream connect error or disconnect/reset before headers. reset reason: connection failure

Note: Log in to the Pod of mesha and access the domain name AppMeshClient.mesh. You will find that it automatically assigns IP "240.240.0.63" and points to the sidecar "envoy", which means that the traffic of the business container will be redirected to the sidecar through DNS Proxy.

Note: By checking the service consumer logs, service provider logs, and data plane enovy logs, it can be seen that the call is made in the istio mesh.
