DogYun German CUVIP line cloud server simple test

How about DogYun? I just had a little bit of prepaid money left, so I opened a cloud server in the German data center of DogYun to try it out. I also posted some simple test information for your reference. I chose Germany not because it is a new node, but mainly because the area is relatively cold. Then, CUVIP (also known as CU2, AS9929, etc.) was added to the line. The domestic delay is good and the bandwidth is sufficient.

Official website: www.dogyun.com

Host Configuration

It is still the old custom with the minimum configuration, elastic cloud server, pay-as-you-go hourly billing mode, single-core CPU (E5-2680v2), 2GB memory, 20GB hard disk, 100M bandwidth, operating system is CentOS7.*, and the computer room is located in Frankfurt, Germany.

Basic Information

DogYun elastic cloud server management is integrated in the member center, including the basic management functions we often use (power on/off, restart, reinstall system, etc.), and also provides resources, traffic monitoring and self-service transfer products, etc. The machine is also given 2 IPv6 by default and an intranet IP is allocated.

IO/Bandwidth Information

The merchant package has limited bandwidth to 100Mbps and IO to 100MB/s. Use the one-click package test

The following test is for uploading/downloading information on three domestic networks. The IO/bandwidth of the machine is consistent with the annotations.

Outbound Routing

Telecom outbound, backbone network to Hong Kong, transfer to China Unicom International AS10099 and then to Germany

Mobile outbound, CMI to US L3 and then to Germany

China Unicom outbound, similar to China Telecom, backbone network to Hong Kong Unicom International AS10099 and then to Germany

Backhaul Routing

The return trip uses a one-click package, which is basically the same for China Telecom and China Unicom. Overseas, it goes to China Unicom International AS10099 and then transfers to AS9929. Domestically, China Telecom AS4143 and China Unicom AS4837 are in place respectively. There are also differences in different regions of China Mobile.

 Beijing Telecom traceroute to 219.141.147.210 (219.141.147.210), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 0.69 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 6.44 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 1.77 ms * Germany, Hesse, Frankfurt, x tom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 14.64 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 16.32 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom6 162.255.48.90 27.57 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom7 162.255.48.229 155.70 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom8 210.78.28.153 158.52 ms * China, Beijing, chinaunicom.com, Unicom9 210.78.30.166 159.03 ms * China, Beijing, chinaunicom.com, Unicom10 202.97.16.61 158.18 ms AS4134 China, Beijing, chinatelecom.com.cn, Telecom13 2.254.120.106.static.bjtelecom.net (106.120.254.2) 161.76 ms AS4847 China, Beijing, chinatelecom.com.cn, Telecom14 bj141-147-210.bjtelecom.net (219.141.147.210) 160.77 ms AS4847 China, Beijing, chinatelecom.com.cn, Telecom---------------------------------------------------------------------
Shanghai Telecom traceroute to 202.96.209.133 (202.96.209.133), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 0.44 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 1.64 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 5.52 ms * Germany, Hesse, Frankfurt, xtom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 18.82 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 16.93 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom6 162.255.48.90 28.53 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom7 162.255.48.229 159.38 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom8 210.78.28.153 157.67 ms * China, Beijing, chinaunicom.com, China Unicom9 218.105.131.126 181.35 ms AS9929 China, Shanghai, chinaunicom.com, China Unicom10 218.105.2.174 239.37 ms AS9929 China, Shanghai, chinaunicom.com, China Unicom11 202.97.16.65 183.91 ms AS4134 China, Shanghai, chinatelecom.com.cn, China Telecom12 *
13 101.95.120.141 181.33 ms AS4812 China, Shanghai, chinatelecom.com.cn, Telecom14 101.95.95.2 186.93 ms AS4812 China, Shanghai, chinatelecom.com.cn, Telecom15 124.74.229.234 184.22 ms AS4812 China, Shanghai, chinatelecom.com.cn, Telecom16 ns-pd.online.sh.cn (202.96.209.133) 181.18 ms AS4812 China, Shanghai, chinatelecom.com.cn, Telecom----------------------------------------------------------------------
Shenzhen Telecom traceroute to 58.60.188.222 (58.60.188.222), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 0.77 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 11.04 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 5.25 ms * Germany, Hesse, Frankfurt, xtom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 41.20 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 16.23 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom6 162.255.48.90 27.52 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom7 162.255.48.229 158.87 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom8 210.78.28.149 169.65 ms * China, Beijing, chinaunicom.com, China Unicom9 218.105.131.122 192.12 ms AS9929 China, Guangdong, Guangzhou, chinaunicom.com, China Unicom10 210.14.161.154 192.12 ms AS9929 197.40 ms * China, Guangdong, Guangzhou, chinaunicom.com, China Unicom11 202.97.81.97 192.38 ms AS4134 China, Guangdong, Guangzhou, chinatelecom.com.cn, China Telecom12 *
13 14.147.127.14 193.09 ms AS134774 China, Guangdong, Shenzhen, chinatelecom.com.cn, Telecom14 *
15 183.56.67.82 194.22 ms AS4134 China, Guangdong, Shenzhen, chinatelecom.com.cn, Telecom16 58.60.188.222 192.88 ms AS4134 China, Guangdong, Shenzhen, chinatelecom.com.cn, Telecom----------------------------------------------------------------------
Beijing Unicom traceroute to 202.106.50.1 (202.106.50.1), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 0.69 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 53.51 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 4.07 ms * Germany, Hesse, Frankfurt, xtom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 27.87 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 14.90 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom6 162.255.48.90 26.40 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom7 162.255.48.229 157.56 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom8 210.78.28.149 157.02 ms * China, Beijing, chinaunicom.com, Unicom9 210.78.30.158 157.07 ms * China, Beijing, chinaunicom.com, Unicom10 219.158.39.57 158.98 ms AS4837 China, Beijing, chinaunicom.com, China Unicom 11 *
13 202.106.50.1 158.65 ms AS4808 China, Beijing, chinaunicom.com, China Unicom----------------------------------------------------------------------
Shanghai Unicom traceroute to 210.22.97.1 (210.22.97.1), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 0.77 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 20.93 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 5.94 ms * Germany, Hesse, Frankfurt, xtom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 13.78 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 14.65 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom6 162.255.48.90 26.41 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom7 162.255.48.229 158.62 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom8 210.78.28.157 157.48 ms * China, Beijing, chinaunicom.com, China Unicom9 218.105.131.126 180.38 ms AS9929 China, Shanghai, chinaunicom.com, China Unicom10 218.105.2.174 180.86 ms AS9929 China, Shanghai, chinaunicom.com, China Unicom11 219.158.44.209 182.19 ms AS4837 China, Shanghai, chinaunicom.com, China Unicom12 219.158.113.197 181.70 ms AS4837 China, Shanghai, chinaunicom.com, China Unicom13 139.226.225.178 180.69 ms AS17621 China, Shanghai, chinaunicom.com, China Unicom14 139.226.201.146 181.87 ms AS17621 China, Shanghai, chinaunicom.com, China Unicom15 210.22.97.1 181.81 ms AS17621 China, Shanghai, chinaunicom.com, China Unicom----------------------------------------------------------------------
Shenzhen Unicom traceroute to 210.21.196.6 (210.21.196.6), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 0.58 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 35.94 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 1.20 ms * Germany, Hesse, Frankfurt, xtom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 14.11 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 14.87 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom6 162.255.48.90 26.48 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom7 162.255.48.229 157.46 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom8 210.78.28.153 157.82 ms * China, Beijing, chinaunicom.com, Unicom9 218.105.131.146 187.03 ms AS9929 China, Guangdong, Guangzhou, chinaunicom.com, Unicom10 210.14.161.62 187.18 ms * China, Guangdong, Guangzhou, chinaunicom.com, China Unicom 11 *
12 219.158.9.73 201.03 ms AS4837 China, Guangdong, Guangzhou, chinaunicom.com, China Unicom13 *
14 120.80.144.34 197.53 ms AS17623 China, Guangdong, Shenzhen, chinaunicom.com, China Unicom15 dns2-ftcg.gdsz.cncnet.net (210.21.196.6) 194.26 ms AS17623 China, Guangdong, Shenzhen, chinaunicom.com, China Unicom----------------------------------------------------------------------
Beijing Mobile traceroute to 221.179.155.161 (221.179.155.161), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 0.72 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 70.68 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 1.20 ms * Germany, Hesse, Frankfurt, xtom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 23.80 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 18.46 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom6 162.255.48.90 27.33 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom7 162.255.48.229 157.52 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom8 210.78.28.153 159.19 ms * China, Beijing, chinaunicom.com, Unicom9 210.78.30.166 158.55 ms * China, Beijing, chinaunicom.com, Unicom10 219.158.35.17 158.30 ms AS4837 China, Beijing, chinaunicom.com, China Unicom 11 *
15 cachedns03.bj.chinamobile.com (221.179.155.161) 204.99 ms AS56048 China, Beijing, chinamobile.com, Mobile----------------------------------------------------------------------
Shenzhen Mobile traceroute to 120.196.165.24 (120.196.165.24), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 0.83 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 6.79 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 0.98 ms * Germany, Hesse, Frankfurt, xtom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 14.15 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 14.75 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom6 162.255.48.90 26.66 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom7 162.255.48.229 157.10 ms AS10099 United Kingdom, London, chinaunicom.com, China Unicom8 210.78.28.145 157.42 ms * China, Beijing, chinaunicom.com, China Unicom9 218.105.131.122 201.05 ms AS9929 China, Guangdong, Guangzhou, chinaunicom.com, China Unicom10 210.14.161.150 210.14.161.151 210.14.161.152 237.70 ms * China, Guangdong, Guangzhou, chinaunicom.com, China Unicom 11 219.158.42.9 192.95 ms AS4837 China, Guangdong, Guangzhou, chinaunicom.com, China Unicom 12 *
14 221.183.71.78 272.63 ms AS9808 China, Guangdong, Guangzhou, chinamobile.com, Mobile15 221.183.110.166 274.94 ms AS9808 China, chinamobile.com, Mobile16 ns6.gd.cnmobile.net (120.196.165.24) 241.36 ms AS56040 China, Guangdong, Shenzhen, chinamobile.com, Mobile----------------------------------------------------------------------
Chengdu Education Network traceroute to 202.112.14.151 (202.112.14.151), 30 hops max, 32 byte packets
 1 45.80.189.254.static.xtom.com (45.80.189.254) 1.05 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 2 147.78.178.209.static.xtom.de (147.78.178.209) 41.98 ms AS3214 Germany, Hesse, Frankfurt, xtom.com
 3 a1.cr01.fra01.xtom.de (91.200.241.20) 1.20 ms * Germany, Hesse, Frankfurt, xtom.com
 4 b5.waves.cr01.lon08.xtom.uk (91.200.241.31) 19.67 ms * United Kingdom, London, xtom.com
 5 162.255.48.9 14.46 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom6 162.255.48.90 28.59 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom7 162.255.48.229 157.54 ms AS10099 United Kingdom, London, chinaunicom.com, Unicom8 210.78.28.149 156.97 ms * China, Beijing, chinaunicom.com, Unicom9 210.78.30.142 157.68 ms * China, chinaunicom.com, Unicom10 219.158.35.33 161.52 ms AS4837 China, Beijing, chinaunicom.com, China Unicom 11 *
12 219.158.103.70 158.24 ms AS4837 China, Beijing, chinaunicom.com, China Unicom13 219.158.39.54 161.60 ms AS4837 China, Beijing, chinaunicom.com, China Unicom14 101.4.116.65 158.60 ms AS4538 China, Beijing, edu.cn, education network15 101.4.116.158 187.80 ms AS4538 China, Sichuan, Chengdu, edu.cn, education network16 *
20 202.112.14.151 186.44 ms AS24355 China, Sichuan, Chengdu, edu.cn, education network

Ping Test

Ping response delay, in general, China Telecom/China Unicom are good, China Mobile is slightly worse. DogYun has many VPS nodes. After the test, I plan to delete them and try other nodes. If you are interested, you can pay attention, or if you want to know which data center, leave me a message.
